Feature-rich MBend includes:

• Transferring parts directly from 3D CAD systems with CAD Link, our optional add-on
• Importing and unfolding IGES and STEP 3D parts
• Importing and folding flat DXFDWG parts with layer filtering
• Enabling automatic or manual selection of tools based on material, machine, and tool properties
• Calculating sequences automatically, avoiding collisions
• Allowing manual selection of sequences, in 3D, with collision testing
• Positioning fingers automatically, yet allowing manual snapping to adjust placement
• Calculating retractions automatically
• Simulating the bending process in 3D, displaying collisions
• Generating native NC programs for loading parts directly into machine controls
• Creating comprehensive setup reports for the machine operator including bend sequence, tooling, and bend-by-bend graphics
• A touch-screen version for machine controls

Advantages of MBend:

• Fully automated processing, including fully automated batch processing of multiple parts, enhancing your productivity and hastening design-to-production times
• Automatic collision-less sequencing solutions for an unlimited number of bends
• If a collision-less bend sequence exists, MBend will find it
• Solutions with a minimal number of stations and segments
• Unlimited number of fingers

For instructional videos on this topic products, go to Metalix YouTube Channel. The list of machines supported in MBend can be found in this link.

Generating NC

• Cincinnati
• CoastOne
• Cybelec
• Delem
• Durma
• ESA
• Komatsu
• Muratec
• Toyokoki
• Trumpf


  Designing Parts

  With the MBend module of designing parts you can draw part profiles.

  Use the MBend design module to sketch a part profile, refine its flange dimensions and angles, and save it in the profile library for later reuse.

  MBend also includes a basic 3D CAD designer.
